150 Watt Pure Sine Wave Inverter

PST-150-12



This high efficiency DC-AC inverter converts 12 Volts DC to 150 Watts of pure sine-wave AC power at 120 Volts, 60 Hz. The unit comes with detachable cable with 12V plug adaptor and cable with battery clamps. Features include overload protection, low battery alarm / shut down, low idle power draw. AC power is available from two NEMA-15R GFCI outlets on the front panel.



3 Year Limited Warranty

Description

Features

  • High efficiency
  • 2x surge
  • Temperature controlled cooling fan – reduces energy consumption
  • Low RF emissions
  • Wide operating DC input range: 10.5 – 16.5 VDC / 21.0 – 33.0 VDC
  • LED indicators for power and protections
  • Low idle power draw
  • Two AC outlets
  • Commercial grade design suitable for heavy duty loads, long periods of continuous operation & for emergency back up
  • UPC – Universal Protection Circuit: low voltage, over voltage, over temperature, over load and short circuit.
  • Detachable cable with 12V plug adapter
  • Detachable cable with battery clamps

Specifications

  • Input: 12 VDC
  • Output: 120 VAC
  • Watts: 150W
  • Weight: 2.8
  • Weight: 1.27
  • Dimensions: 6.1 x 8.31 x 2.58 (in)
  • Dimensions: 155 x 211 x 65.5 (mm)
  • Safety: Certified to UL & CSA Standards
