Description
Features
- High efficiency
- Commercial Grade
- Lightweight
- Quiet operation
- Industry Proven Design – 1000s of units in operation
- User Selectable ( by DIP Switch) for 2 or 3 stage, rapid and safe charging of stand-alone and loaded Lead Acid Batteries
- 120 VAC, 50/60 Hz (default) or 230 VAC, 50/60 Hz (internal jumper setting)
- Voltage meter display – Ammeter and LED power status
- For all types of Lead Acid batteries
- Charge with a battery load or stand alone
- Use as a power supply or DC UPS
- UPC: Universal Protection Circuit – short circuit, overload, reverse battery polarity
- Charge 3 banks of batteries at once – no isolator necessary
Specifications
- Input: 120 VAC, 50/60 Hz (default) or 230 VAC 50/60 Hz (internal jumper setting)
- Output: 12 VDC
- Amps: 30 Amps
- Weight: 6.4 (lbs)
- Weight: 2.9 (kg)
- Dimensions: 11.0 x 8.4 x 3.3 (in)
- Dimensions: 28.0 x 21.4 x 8.3 (cm)
- Safety: Intertek-ETL listed: Conforms to ANSI/UL Standard 1564 ; Certified to CAN/CSA STD. C22.2 No. 107.2
WARNING: Cancer and Reproductive Harm –
www.P65Warnings.ca.gov – State of California only.
Downloads
Applications
- Automotive
- Recreational vehicles
- Marine
- Communications sites
- Battery back-up systems
